3-Deflector semi-industrial chute with greasable hinges and removable access panel.
PC3C-GR1.5
CHOICE OF ADJUSTMENT FOR CHUTE DEFLECTOR
Hydraulic cylinder (included)
25TR04
Hose support for deflector cylinder
TSB-4864
Manual telescopic tube
T-4864
HYDRAULIC MOTOR FOR CHUTE ROTATION
Hydraulic motor (included)
MLH-250-R
HOSE KITS
PKB-GR1
Hose kit for basic functions. Includes hydraulic hoses connecting the tractor oil outlets to the deflector adjustment cylinder and the chute rotation motor. * Installation not included.
PKB-GR1
LATERAL BLADES
CL-4872
Kit of 2 lateral blades, standard steel (3/8" x 2 1/2" x 39 1/2")
CL-4872
SCRAPER BLADE
SIT1-154
TV-154
SST-154
Semi-industrial scraper blade, Hardox 450, reversible, 1/2" x 3 1/2"
SIT1-154
TIVAR scraper blade, 1" thick, not reversible, including mounting kit
TV-154
Stainless steel scraper blade, reversible, 1/2" x 3 1/2"
SST-154
SKID SHOES
PHD-4872
PST-4872
Industrial skid shoes with Hardox 450 soles
PHD-4872
Skid shoes with stainless steel soles
PST-4872
SPEED REDUCER
PR-7502-1
PR-7202-2
PRC-6502-1
Inverter 540/540 RPM (1:1) - 75 HP at 540 RPM - 2 gears - shafts 4.855" c/c
PR-7502-1
Speed reducer inverter 1000/555 RPM (1.8:1) - 85 HP at 1000 RPM - 2 gears - shafts 4.855" c/c
PR-7202-2
Non-inverting PTO drop box 540/540 RPM (1:1) - 55 HP at 540 RPM - chain - shafts 6.5" c/c
PRC-6502-1
CHOICE OF POWER TAKE-OFF (PTO)
T50 PTO 1 3/8"-6 & 1 3/8"-6 (540 RPM)
8114
T60 PTO 1 3/8"-6 & 1 3/8"-6 (540 RPM)
8202
T60 PTO 1 3/8"-21 & 1 3/8"-6 (1000 RPM)
8202-1
RUBBER DEFLECTOR FLAP
Rubber deflector flap located from the top of the frame to the auger. Reduces projections.
TL-5480
CHOICE OF COLORS
Red PRONOVOST
Blue
PG1-02
Orange
PG1-04
Yellow INDUSTRIAL
PG1-06
Green
PG1-07
Black
PG1-10
Other recommended products
Additional Information
HYDRAULIC DRIVEN
It is possible to use this snowblower with hydraulic drive. The hydraulic oil flow at a specific pressure will guide you in to the choice of the snowblower.
Contact your Pronovost dealer to obtain a quote for your specific requirements.
Complete specifications
HP recommended (min. - max.)
45 to 65 HP PTO
Working width
54" / 1371 mm
Cutting height
30" / 762 mm
Hitch category
1
Cutting height of lateral blades
39 1/2" / 1003 mm
Impeller diameter
26" / 660 mm
Depth of drum
12" / 305 mm
Impeller housing contour : Hardox 450
Included
Number of impeller blades
4
Impeller shaft diameter
1 9/16" / 40 mm
Height of impeller center
16 1/2" / 419 mm
Rotor RPM
540 RPM
Required RPM for the tractor PTO
540 RPM (Opt. 1000 RPM)
Number of augers
1 open flight, double ribboned, serrated auger
Main auger diameter
25" / 635 mm
Bearing / ductile iron housing
1 1/4" / 32 mm
Drive chain - Main auger
60
Number of shear bolts
1 for impeller + 1 for auger
Drive shaft included (optional)
T50 (T60)
Lateral blades - High quality steel
Opt.
Scraper blade - High quality steel
3/8" x 3 1/2" reversible
Scraper blade - Semi-industrial made of Hardox 450
Opt.
Scraper blade - Tivar
Opt.
Scraper blade - Stainless steel
Opt.
Adjustable skid shoes - Quick adjustment high quality steel
