P-922 / P-922TRC
| HP recommended | 90 - 125 HP PTO |
| Working width | 92" | 2336 mm |
| Cutting height | 44" | 1118 mm |
| Impeller diameter | 34" | 864 mm |
| Weight including chute | 2240 lbs | 1016 kg 9 |
| Weight including chute (TRC model) | 2540 lbs | 1151 kg 9 |
P-922 / P-922TRC
| HP recommended | 90 - 125 HP PTO |
| Working width | 92" | 2336 mm |
| Cutting height | 44" | 1118 mm |
| Impeller diameter | 34" | 864 mm |
| Weight including chute | 2240 lbs | 1016 kg 9 |
| Weight including chute (TRC model) | 2540 lbs | 1151 kg 9 |
- Options
- Other products recommended
- Complementary informations
- Complete specifications
- Photos/videos
Options
| List of options as per combo.
Important : If you prefer, you can also adjust your configuration according to your needs by choosing from the options below. |
Combo P-922 9225 | PTO PSIG-7486 | Semi-industrial chute MLH-315-R | Chute rotation motor 25TR08 | Deflector cylinderCombo P-922TRC 9225 | PTO PSIG-7486 | Semi-industrial chute MLH-315-R | Chute rotation motor 25TR08 | Deflector cylinder MLH-315-R | Drum rotation motor |
| Semi-industrial chute with greasable hinges and access panel (removable) | PSIG-7486 |
| Quick attach industrial chute with greasable hinges and access panel (removable) | PCG-7486 |
| • 24" Extension for industrial chute | PRP-7486-2 |
| • 48" Extension for industrial chute | PRP-7486 |
| Hydraulic telescopic industrial chute with greasable hinges and access panel, including extensions cylinders and hose support + hose support for deflector cylinder. Includes replacement of chute base for telescopic chute. | PCT-7486-HDB |
| • Mounting kit for working light on telescopic chute. | PKL-IND |
| Hydraulic cylinder (included) | 25TR08 |
| Hydraulic motor (included) | MLH-315-R |
| Hose kit for basic functions. Includes hydraulic hoses connecting the tractor oil outlets to the deflector adjustment cylinder and the chute rotation motor. * Installation not included. | PKB-GR3 |
| Kit for TRC models, also includes hoses for drum rotation motor. * Installation not included. | PKB-GR3TRC |
| Kit for models with telescopic chute PCT-7486-HDB, also includes hoses for chute lifting cylinders. * Installation not included. | PKB-GR3-T |
| Kit for TRC models with telescopic chute PCT-7486-HDB, also includes hoses for chute lifting cylinders. * Installation not included. | PKB-GR3TRC-T |
| Lateral blades, high quality steel 3/8" x 4" x 62" | CL-8292 |
| Semi-industrial scraper blade, carbon steel 450, reversible 1/2" x 4" not sharpened | SIT1-92 |
| Industrial scraper blade, carbon steel 450, not reversible 1/2" x 6" sharpened | T1-92 |
| Tivar scraper blade including mounting kit | TV-92 |
| Stainless Steel scraper blade, reversible, 1/2" x 4" not sharpened | SST-92 |
| Industrial skid shoes with Hardox 450 soles | PHD-92104 |
| Skid shoes with ROCKTEC soles | PSHD-92104 |
| Skid shoes with stainless steel soles | PST-92104 |
| Full flight serrated main auger | VIP2-992 |
| Speed reducer 1000/555 RPM - 220 HP at 1000 RPM - 3 gears - shafts 7 1/16" c/c | PRH-30M-2 |
| Drop box 1000/540 RPM. Two choices of input shafts : Reducer inverter 225 HP at 1000 RPM 2/3 gears - shafts 6 3/4" c/c or reducer only 175 HP at 1000 RPM 3/3 gears - shafts 8" c/c | PRH-25M-2 |
| T80 PTO 1 3/8"-6 & 1 3/4"-20 (540 RPM) | 9225 |
| T80 PTO 1 3/8"-21 & 1 3/4"-20 (1000 RPM) | 9569 |
| T80 PTO 1 3/4"-20 & 1 3/4"-20 (1000 RPM) | 9569-1 |
| V80 Multilobe PTO 1 3/8"-6 & 1 3/4"-20 (540 RPM) | 9225-V |
| V80 Multilobe PTO 1 3/8"-21 & 1 3/4"-20 (1000 RPM) | 9569-V |
| T90 PTO 1 3/8"-6 & 1 3/4"-20 (540 RPM) | 9475 |
| T90 PTO 1 3/8"-21 & 1 3/4"-20 (1000 RPM) | 9475-1 |
| T90 PTO 1 3/4"-20 & 1 3/4"-20 (1000 RPM) | 9475-2 |
| V90 Multilobe PTO 1 3/8"-6 & 1 3/4"-20 (540 RPM) | 9598 |
| V90 Multilobe PTO 1 3/8"-21 & 1 3/4"-20 (1000 RPM) | 9599 |
| V90 Multilobe PTO 1 3/4"-20 & 1 3/4"-20 (1000 RPM) | 9604 |
| Hydraulic motor (included on TRC model) | MLH-315-R |
| Impeller housing contour made from Hardox 450 steel in lieu of regular grade steel | TBHD-3412 |
| Impeller housing contour made from Hardox 450 steel in lieu of regular grade steel (for TRC model) | TBHD-3412TRC |
| Rubber deflector flap located from the top of the frame to the auger. Reduces projections. | TL-9298 |
| PRONOVOST Red | Included |
| Blue | PG2-02 |
| Orange | PG2-04 |
| INDUSTRIAL Yellow | PG2-06 |
| Green | PG2-07 |
| KIO Orange | PG2-09 |
| Black | PG2-10 |
Complementary informations
HYDRAULIC DRIVEN
It is possible to use this snowblower with hydraulic drive. The hydraulic oil flow at a specific pressure will guide you in to the choice of the snowblower.
Contact your Pronovost dealer to obtain a quote for your specific requirements.
HYDRAULIC WHEELS FOR SNOWBLOWERS
Hydraulic wheels permit using the snowblower at a constant height from the ground without scraping it. Practical to avoid blowing gravel, they permit snowblowing on a grassy surface while avoiding direct contact of the blade with the ground.
*Available only on a new snowblower made in production.
Contact your Pronovost dealer to obtain a quote for your specific requirements.
ICE SCRAPER BLADE FOR SNOWBLOWERS
The ice scraper blade is installed under the snowblower, easily and requires no tool.
Scrape icy surfaces to create a grooved finich that increases grip. Its design requires no additional oil outlet or any modification to the snowblower.
When required, the ice scraper blade must be assembled to the snowblower and then disassembled after use.
Contact your Pronovost dealer to obtain a quote for your specific requirements.
SNOW ROLLER FOR SNOWBLOWERS
Lifts the snowblower by 3 inches.
Allows for compacting a uniform snow base while keeping the snowblower elevated to prevent gravel from entering. Perfect for the start of the season. Compatible with our most popular models.
Click here to watch the presentation video.
Contact your Pronovost dealer to obtain a quote for your specific requirements.
CHUTE HEIGHTS
To view the table of chute height measurements, click on the link below :
Chute heights table
Complete specifications
| HP recommended | 90 - 125 HP PTO |
| Working width | 92" | 2336 mm |
| Cutting height | 44" | 1118 mm |
| Cutting height of lateral blades | Option CL : 62" | 1575 mm |
| Lateral blades - High quality steel | Option : CL-8292 3/8" x 4" |
| Height - Chute base | 44" | 1118 mm |
| Height of chute base (TRC model) | 49" | 1245 mm |
| Height with telescopic chute | PCT-7486-HD : 112" | 2845 mm closed, 144" | 3658 mm extended |
| Height with telescopic chute (TRC model) | PCT-7486-HD : 117" | 2972 mm closed, 149" | 3785 mm extended |
| Impeller diameter | 34" | 864 mm |
| Depth of drum | 12" | 305 mm |
| Impeller housing contour : High quality steel | Included |
| Impeller housing contour : Hardox 450 | Option |
| Number of impeller blades | 6 |
| Impeller shaft diameter | 2" | 51 mm |
| Height of impeller center | 21" | 533 mm |
| Rotor RPM | 540 RPM |
| Required RPM for the tractor PTO | 540RPM - Opt. 1000 RPM |
| Number of augers | 2 |
| Main auger diameter | 23" | 584 mm |
| Upper auger diameter | Option : 14" | 355 mm |
| Drive chain - Main auger | 80 |
| Hitch category | 2 - 34 1/2" | 876 mm c/c |
| Number of shear bolts | 1 for impeller + 1 for auger |
| Drum rotation for hydraulic motor (TRC only) | Included with MLH-315-R and cushion valve |
| PRH-25M-2: Drop box 1000/540 RPM. Two choice of input shafts : Speed reducer and inverter 225 HP at 1000 RPM 2/3 gears - shafts 6 3/4" c/c or non-inverter reducer 175 HP at 1000 RPM 3/3 gears - shafts 8" c/c | Option : PRH-25M-2 |
| PRH-30M-2: Speed reducer 1000/555 RPM - 220 HP at1000 RPM - 3 gears - shafts 7 1/16" c/c | Option : PRH-30M-2 |
| Scraper blade - High quality steel | Included : 1/2" x 4" reversible, not sharpened |
| Scraper blade - Semi-industrial made of Hardox 450 | Option : SIT1-92 1/2" x 4" reversible, not sharpened |
| Scraper blade - Industrial made of Hardox 450 | Option : T1-92 1/2" x 6" not reversible, sharpened |
| Scraper blade - Tivar | Option : TV-92 1" thickness, not reversible, not sharpened |
| Scraper blade - Stainless steel | Option : SST-92 1/2" x 4" reversible, not sharpened |
| Adjustable skid shoes - Quick adjustment high quality steel | Included |
| Adjustable skid shoes - Quick adjustment Hardox 450 | Option : PHD-92104 |
| Adjustable skid shoes - Quick adjustment Hardox 600 | Option : PSHD-92104 |
| Adjustable skid shoes - Quick adjustment stainless steel | Option : PST-92104 |
| Full flight main auger (industrial) | Option : VIP2-992 |
| Chute - Semi-industrial with greasable hinges and removable access panel | Included : PSIG-7486 |
| Chute - 24" extension | Option : PRP-7486-2 |
| Chute - 48" extension | Option : PRP-7486 |
| Chute - Telescopic including extension cylinders | Option : PCT-7486-HDB |
| Chute rotation system - Hydraulic motor kit (motor not included) | Included with MLH-315-R and cushion valve |
| Chute maximum rotation angle - Hydraulic motor | 270° to 335° adjustable |
| Antifriction for chute | Included : ring |
| Deflector - Hydraulic cylinder option | Included : 25TR08 |
| Bearing / ductile iron casting | 1 1/2" | 38 mm |
| PTO | Included : T80 - Options : V80, T90 & V90 |
| Color (including primer) | Included : Pronovost Red Opt. : Choice of 6 colors |
| Storage support | Included |
| Weight including chute | 2240 lbs | 1016 kg 9 |
| Weight including chute (TRC model) | 2540 lbs | 1151 kg 9 |
Design and specifications subject to change without notice.
1 Weight without drive shaft.
2 Weight including chute.
3 Weight without chute.
4 Including chute PSIG-7486, drive shaft and hydraulic motor.
5 Including chute and cylinder.
6 Weight including chute, chute cylinder and rotation hydraulic motor.
7 Weight including telescopic chute.
8 Weight including telescopic chute and reducer.
9 Weight with chute PSIG.
